Shaabadaynta/Isku dhejinta Robot SDCX RMD-300/200/160/120/35/08/110/20/50

Hordhac kooban oo ku saabsan badeecada

Robot shaabadeynta ayaa si weyn loogu isticmaalaa isugeynta, dejinta, gaadiidka iyo howlaha kale ee dhinacyada baakadaha, cabitaanka, warshadaha kiimikada, cuntada, iwm.

NALA SOO XIRIIR

Faahfaahinta Alaabta

Tags Product

Qiyaasaha Farsamada

Qaabka No.	Degree of Freedom	Habka wadista	Qaadashada (KG)	Saxnaanta meelaynta soo noqnoqda (mm)	Qiyaasta dhaqdhaqaaqa (°)				Xawaaraha ugu badan (°/s)				Culayska la oggol yahay ee dhaqdhaqaaqa curcurka (kg·m²)	garaac wareeg ah (wareeg/sacad)	Raadiyaha dhaqdhaqaaqa (mm)	Miisaanka deegaanka (kg)
Qaabka No.	Degree of Freedom	Habka wadista	Qaadashada (KG)	Saxnaanta meelaynta soo noqnoqda (mm)	J1	J2	J3	J4	J1	J2	J3	J4		garaac wareeg ah (wareeg/sacad)	Raadiyaha dhaqdhaqaaqa (mm)	Miisaanka deegaanka (kg)
SDCX-RMD300	4	AC servo wadista	300	±0.5	± 180	± +100~-44	± +121~-15	± 360	85	90	100	190	134	1000^③	3150	1500
SDCX-RMD200	4	AC servo wadista	200	±0.3	± 180	± +100~-44	± +121~-15	± 360	105	107	114	242	78	1300^③	3150	1500
SDCX-RMD160	4	AC servo wadista	160	±0.3	± 180	± +100~-44	± +121~-15	± 360	123	123	128	300	78	1500^③	3150	1500
SDCX-RMD120	4	AC servo wadista	120	±0.3	± 180	± +100~-44	± +121~-15	± 360	128	126	135	300	78	1560^③	3150	1500
SDCX-RMD50	4	AC servo wadista	50	±0.2	± 178	± +90 ~ -40	± +65~-78	± 360	171	171	171	222	4.5	1700^②	2040	660
SDCX-RMD20	4	AC servo wadista	20	±0.08	± 1170	± +115~-25	± +70~-90	± 360	170	170	185	330	0.51	1780kii^①	1720kii	256
SDCX-RMD08	4	AC servo wadista	8	±0.08	± 170	± +90 ~ -40	± +68~-90	± 360	251	195	195	367.5	0.25	1800^①	1433	180

Hadalo:

① Jidka imtixaanku waa 150mm sare iyo 1000mm ballaaran, iyo wakhtiga wareegga dhabta ah waxaa saameeya xaaladaha shaqada dhabta ah;

② Jidka tijaabada ah waa 200mm sare iyo 1000mm ballaaran, iyo waqtiga wareegga dhabta ah waxaa saameeya xaaladaha shaqada dhabta ah;

③ Jidka imtixaanku waa 400mm sare iyo 2000mm ballac ah, iyo wakhtiga wareegga dhabta ah waxaa saameeya xaaladaha shaqada dhabta ah;

Iska ilaali inaad la xiriirto gaasaska guban kara, qarxa iyo daxalka;Samee yaan lagu daadin biyo, saliid iyo boodh;Ka fogow ilaha qaylada korantada (plasma)
